What is the working principle of a small hydraulic core drilling rig?
August 10 , 2024
The oil pump sucks oil from the oil tank through the oil filter, and the discharged pressure oil enters the control valve through the pipeline. The system pressure can be adjusted by the overflow valve on the control valve to control the pressure in the system. So that the drilling rig can operate normally. At the same time, the system pressure can be quickly increased by the fast boost handle to make the feeding cylinder rise and fall quickly. The reversing rod on the control valve can be used to control the direction of oil inlet and outlet. Outside the feeding cylinder, the feeding cylinder can be weighed, lifted, lowered, stopped, etc. A one-way butterfly valve is installed between the lower chamber of the oil cylinder and the operating valve to adjust the descending speed of the vertical axis. Since the valve does not have a one-way valve, it does not affect the rapid lifting and lowering of the vertical axis.
Learn More >
Horizontal directional drilling machine
August 05 , 2024
Horizontal directional drilling rig is a construction machine, it can lay a variety of underground utilities (pipelines, cables, etc.) without excavating the surface of the ground. It is widely used in laying of flexible pipelines for water supply, electricity, telecommunications, natural gas, coal gas, oil, etc. It is suitable for sand, clay, and other conditions, but not suitable for high groundwater levels and pebble formations. It can be constructed in most non-hard rock areas . The working environment temperature is -15℃~+45℃. Horizontal directional drilling technology is a new construction technology that combines the directional drilling technology of the petroleum industry with traditional pipeline construction methods. It has the characteristics of fast construction speed, low construction accuracy, and low cost. It is widely used in the laying of pipelines for water supply, coal gas, electricity, telecommunications, natural gas, oil, etc. Horizontal directional drilling equipment has also achieved rapid development in the past decade years and has become an emerging industry in developed countries. Its development trend is towards large-scale and miniaturization, adaptability to hard rock operations, self-contained anchoring system, automatic stacking and extraction of drill pipes, automatic lubrication of drill pipe connections, anti-electric shock system and other automated operation functions, ultra-deep...
Learn More >
UY500 Water Well Drilling Rig
July 29 , 2024
Features of UY500 water well drilling rig: 1. Engine: well-known brand Guangxi Yuchai turbocharged engine or American Cummins brand turbocharged engine; 2. Travel device: equipped with new travel motor and reducer, long service life; 3. Hydraulic oil pump: imported from Italy, parallel gearbox design, oil pump separation; 4. Sufficient and reasonable power distribution: advanced hydraulic system with unique design, simple maintenance and low cost; 5. Power head device: the box body is integrated, the dual motor provides greater power, greater torque, more durable, and lower maintenance cost; 6. Drilling rig chassis: (professional drilling rig chassis), classic and durable, heavy load-bearing, wide chain plate width, and less damage to hard roads; 7. Lifting force: adopts designed composite boom, small boom size, long stroke, double cylinder lifting force, and large drilling rig lifting tonnage; 8. Each hydraulic oil pipe is covered with a thickened protective cover to extend the service life of the oil pipe; 9. Independent heat dissipation dual system adopts hydraulic oil temperature cooling and is equipped with traditional air cooling. Long engine life 10. Dual systems: 1. Air power system with air compressor 2. Mud pump system with mud pump
Learn More >
UY300 Water Well Drilling Rig Machine
July 05 , 2024
Features of UY300 water well drilling rig: 1. It is an efficient and multifunctional underground water well drilling equipment, which can be used for drilling water wells, agricultural irrigation wells, geothermal wells and other types of wells. It is especially suitable for water extraction projects in mountainous areas and rock formations. 2. This machine can drill holes in different strata (rock layer, mud layer, sand layer), with a maximum aperture of up to 300mm. 3. This machine uses a large-torque hydraulic motor power head and brand diesel, and the hydraulic control system uses a large-diameter hydraulic cylinder. The brand diesel is protected by a 2-stage air filtration system, and clean air from an air compressor can also be used directly. 4. The unique bump design and centrally controlled operating system are easy to maintain and convenient for machine operation. 5. This machine uses an excavator crawler chassis with high off-road performance. It can also be installed on a truck for greater maneuverability. 6. The two gear rotation and feed speed enable it to work in soil and rock layers. 7. Dual systems can be added: 1. Air power system with air compressor 2. Mud pump system with mud pump
Learn More >
What are the advantages of small water well drilling rigs?
June 25 , 2024
A small water well drilling rig is a modern mechanical equipment designed for groundwater resource development. It has the remarkable advantages of easy operation, high efficiency and speed, economical and practical, low noise, flexible and convenient, self-unloading drill rod design, and environmental protection and energy saving. It is widely used in rural and remote areas. 1. Easy operation The design of small water well drilling rig takes full account of the user’s convenience of operation. One person can operate it skillfully without complex professional skills, which is particularly important for the lack of technical personnel in many rural and remote areas. Even an inexperienced novice can master the basic operation in a short time, which greatly reduces labor costs and training time. 2. Efficient and fast The small water well drilling rig can reach a hole-making speed of about 10 meters per hour, which greatly improves work efficiency. This means that an ordinary rural family can easily complete the task of drilling a well in one day, thereby quickly obtaining clean groundwater. The efficient operation speed not only saves time, but also reduces the impact on the surrounding environment and residents’ lives during construction. 3. Economical and practical The small...
Learn More >
UY350 water well drilling rig
June 18 , 2024
Features of UY350 water well drilling rig: 1. The rotation is driven by dual motors, with large torque, small size and adjustable speed 2. The triple gear pump is used to ensure that the oil pump is durable and reliable 3. The combined platform has a beautiful design, equipped with pedals, and is easy to operate. 4. Equipped with clutch and auxiliary radiator, it is suitable for areas with high altitude and cold climate. 5. Travel motor with German technology; high torque and climbing ability, low failure rate 6. Dual systems can be added: air power system with air compressor or mud pump system with mud pump Main parameter of UY350： The hole diameter: 140-325mm Drilling depth: 350m Diesel engine: 91kw Drill pipe diameter: Φ89 / Φ102
Learn More >
